Compact 3W LED Spot Light for Machine Vision Inspection

Compact 3W LED Spot Light for Machine Vision Inspection

The POMEAS PMS-VP6025-08 (3W) is a compact LED spot light developed for machine vision and industrial inspection applications. Featuring a small Ø25 mm housing and concentrated illumination, it is particularly suitable for inspection systems requiring a compact light source and stable image brightness.

Its compact structure allows easy installation in space-limited automation equipment and machine vision systems. The light can be used for small-part inspection, positioning, recognition and microscope-assisted imaging.

Key Features

• 3W High Brightness: Concentrated LED illumination for small inspection areas.
• Compact Ø25 mm Housing: Designed for machine vision systems with limited installation space.
• Stable Illumination: Consistent light output helps maintain reliable imaging conditions.
• Compact 60 mm Length: Easy to integrate into industrial equipment and inspection stations.
• Flexible Installation: Two M3 mounting holes simplify mechanical integration.
• Color Options: White LED configuration with red illumination available as an alternative option.

Technical Specifications

Compact Design for Machine Vision

With an overall length of only 60 mm and a maximum housing diameter of Ø25 mm, the PMS-VP6025-08 can be installed close to cameras, lenses and inspection targets without occupying excessive space.

The compact form factor makes the light suitable for machine vision stations where cameras, optics, fixtures and motion components must be integrated within a limited mechanical envelope.

Stable Illumination for Reliable Imaging

Stable illumination is essential for reliable machine vision inspection. The PMS-VP6025-08 provides concentrated LED lighting to help improve visibility and image consistency when inspecting small components and localized target areas.

Its compact metal housing also provides a practical structure for industrial integration and continuous inspection applications.

Typical Applications

• Small component inspection
• Machine vision inspection
• Compact automated inspection systems
• Positioning and detection
• Code and character recognition
• Microscope-assisted inspection
• Industrial automation equipment

Small Component Inspection

The concentrated illumination is suitable for inspecting small mechanical parts, electronic components and localized surface features where a large area light source is unnecessary.

Microscope and Optical Inspection

POMEAS spot lights can also be integrated with microscope lenses and optical inspection systems to provide focused illumination for small targets. This makes the PMS-VP6025-08 suitable for precision observation and machine vision systems requiring compact auxiliary lighting.

Mechanical Dimensions

• Overall Length: 60 mm
• Maximum Outer Diameter: Ø25 mm
• Front Diameter: Ø14 mm
• Middle Diameter: Ø7.95 mm
• Neck Length: 11.85 mm
• Tip Length: 8 mm
• Mounting: 2-M3, Depth 4 mm
• Mounting Hole Spacing: 12 mm

Why Choose POMEAS Machine Vision Lighting?

POMEAS provides machine vision lighting solutions for industrial inspection, measurement and automation applications. Lighting configuration can be selected according to the target characteristics, working distance, illumination angle, required field of view and imaging requirements.
