4K Big FOV Machine Vision Lens | 1" C-Mount Industrial Zoom Lens

4K Big FOV Machine Vision Lens - 1" C-Mount Industrial Zoom Lens (PMS-LZH-7501W-05)

Product Description

The Pomeas PMS-LZH-7501W-05 is a premium 4K big FOV high-resolution zoom lens engineered specifically for high speed detection and accurate machine vision applications. Designed with higher resolution requirements, its horizontal resolution when paired with a 1 inch sensor camera easily reaches the 4K level. Compared with traditional zoom systems, this advanced industrial camera lens expands the field of vision by more than 145% at the same magnification, making it an ideal choice for high-throughput automated inspection.

Key Advantages & Features

• 145% Expanded Field of View (FOV): Supports 1" large-format sensor cameras, drastically increasing the inspection area per frame compared to conventional lenses.
• 4K High-Resolution Output: Delivers crisp, line-pair-optimized imaging across the entire 0.68x to 5x magnification spectrum for flawless defect tracking.
• Engineered for High-Speed Systems: The combination of a large numerical aperture (NA) and big FOV enables faster optical scanning, cutting down cycle times in automated lines.
• Versatile Modular Design: Offers multiple magnification TV tubes, alternative camera mounts (C-Mount / M42 Mount), and optional lens attachments to fit specific optical pathways.
• Flexible Zoom Control: Available in both manual adjustments and motorized zoom lens configurations for seamless software-driven calibration.

Technical Specifications

Target Application Fields

This big FOV 4K machine vision lens is widely integrated into high-precision, automated systems within the following industries:

• Semiconductor Manufacturing: Fast wafer inspection, micro-component alignment, and die bonding testing.
• Electronics & PCB AOI: High-speed surface mount technology (SMT) verification and multi-point solder joint inspection.
• Lithium Battery Automated Lines: High-speed dimension gauging, continuous film surface defect scanning, and alignment.
• Biological & Medical Imaging: Automated slide scanning and high-throughput micro-fluidic chip analysis.

Frequently Asked Questions (FAQ)

Q1: How does the PMS-K75C-C lens achieve a 145% improvement in the field of view?

A: Through a specialized wide-field optical design optimized for 1" format sensors. At the identical magnification level of a traditional zoom system, the PMS-LZH-7501W-05 allows more light and data from the edges to hit the sensor, expanding the captured field of view by more than 1.45x and speeding up overall inspection throughput.

Q2: Does this 4K big FOV zoom lens support camera interfaces other than C-mount?

A: Yes. While it natively comes with a standard C-mount interface to match most industrial camera lens specifications, its modular selection diagram supports M42 mounts and custom adapter rings to fit varied high-resolution, large-format sensors.
