150 mm Chromatic Confocal Displacement Sensor with ±35 mm Range

Main Features

The SFS-D700150 is a long-range chromatic confocal displacement sensor designed for non-contact precision measurement in industrial inspection and automation systems .

• 150 mm reference distance
• Wide ±35 mm measuring range
• Total measuring span of 70 mm
• Linearity error of less than ±2 μm
• Repeatability of 1550 nm
• Small Φ43 μm measuring spot
• Measurement angle up to ±5.5°
• Compact Φ50 × 120.5 mm sensor body
• Lightweight 207 g design
• IP40 protection rating

Technical Highlights

Long Reference Distance

The 150 mm reference distance provides more installation space between the sensor and the measured object. This makes it easier to integrate lighting, fixtures, moving parts, and other inspection components.

Wide Measuring Range

With a ±35 mm measuring range, the sensor provides a total measuring span of 70 mm. It is suitable for objects with larger height differences or position variations.

Stable Precision Measurement

The SFS-D700150 offers 1550 nm repeatability and a linearity error of less than ±2 μm, supporting stable displacement, height, and surface profile measurement.

Non-Contact Optical Measurement

The chromatic confocal measuring principle allows the sensor to measure without physically touching the object, helping prevent surface damage and mechanical wear.

Flexible Measurement Angle

The sensor supports measurement angles up to ±5.5°, making it suitable for surfaces that may not be completely perpendicular to the sensor.

Typical Applications

The SFS-D700150 can be used in a wide range of industrial measurement and automated inspection applications, including:

• Height and displacement measurement
• Surface profile inspection
• Step height measurement
• Position and dimensional inspection
• Metal component inspection
• Mold and machined part measurement
• Automated production line inspection
• Large-range surface variation measurement
• Precision component quality control
• Non-contact measurement in limited-access areas

Technical Specifications

Frequently Asked Questions

What is the measuring range of the SFS-D700150?

The sensor has a measuring range of ±35 mm, providing a total measuring span of 70 mm.

What is the reference distance?

The reference distance is 150 mm, measured from the sensor to the center of the measuring range.

Is this a contact or non-contact sensor?

The SFS-D700150 uses non-contact chromatic confocal optical measurement, so the sensor does not need to touch the measured object.

What is the measurement repeatability?

The sensor provides a repeatability of 1550 nm under the specified test conditions.

What is the linearity error?

The linearity error is less than ±2 μm.

Can the sensor measure angled surfaces?

Yes. The sensor supports a measurement angle of up to ±5.5° under the specified test conditions.

What is the measuring spot size?

The measuring spot diameter is approximately Φ43 μm.

What are the dimensions and weight of the sensor?

The sensor measures Φ50 × 120.5 mm and weighs approximately 207 g.

Is the sensor waterproof?

The sensor has an IP40 protection rating . It is intended for use in clean industrial environments and should be protected from water, oil, and heavy dust.

Does the sensor require a controller?

The sensor is normally used with a compatible chromatic confocal controller. The controller model, output interface, sampling rate, and system configuration should be confirmed according to the application requirements.

More answers about product selection and system integration are available in the POMEAS FAQ Center .

Related Measurement Solutions

The SFS-D700150 is suitable for single-point displacement, height, and surface profile measurement. For continuous 2D or 3D profile scanning, explore our line laser displacement sensor solutions .

Need Help Selecting a Sensor?

Please provide your target material, measuring range, required accuracy, installation distance, controller interface, and sampling requirements. Our application team can help evaluate the appropriate sensor and system configuration.

Contact POMEAS Application Support
