35mm 1-Inch 10MP C-Mount FA Industrial Lens

MH2035-10MP is a POMEAS 10MP fixed-focal FA industrial lens, 35mm focal length, sensors up to 1" (16mm), C-mount, aperture F2.0-close, focus range 0.2m~∞, distortion 0.28% (1"), for industrial inspection and dimensional measurement.

SKU:

Description
Parameters
Files (0)

Product Overview

POMEAS MH2035-10MP is a 10MP fixed-focal FA industrial lens with a 35mm focal length, supporting sensors up to 1" (16mm), C-mount. The diagonal field of view on 1" format is 26.10°, with distortion of 0.28% at y=8.0mm. Focus range 0.2m~∞, manual focus and manual iris, suitable for industrial inspection, dimensional measurement and automated identification in machine vision applications.

Key Features

High-resolution 10MP fixed-focal design
35mm focal length, 1" diagonal FOV 26.10° on 1" format
Supports sensors up to 1" (16mm)
Low distortion 0.28%@y=8.0mm (1")
Aperture F2.0-close, focus range 0.2m~∞
Weight 70.35g

Specifications

Model	MH2035-10MP
Type	Fixed-Focal FA Industrial Lens
Resolution	10MP
Max Sensor Format	1" (16mm)
Mount	C-Mount
Aperture	F2.0-close
Focal Length	35mm
Distortion (1")	0.28%@y=8.0mm
Back Focal Length (in air)	12.9mm
Focus Range	0.2m~∞
FOV (1", D×H×V)	26.10°×20.83°×15.72°
Object Size at Min. Focus (D×H×V, 1")	81.10×64.88×48.66mm
Filter Thread	M30.5×P0.5
Weight	70.35g
Operating Temperature	-20°C～+60°C
Wavelength	420~1000nm
Operation	Manual focus / manual iris
